U-Line - 36" 3000 Series Dual-Zone Wine Refrigerator - U-3036WCWCS-00B

U-Line - 36" 3000 Series Dual-Zone Wine Refrigerator - U-3036WCWCS-00B

Our 36" 3000 Series Dual-Zone Wine Refrigerator is a wine lover’s dream. This product features two independently controlled temperature zones with convection cooling for quick and consistent temperatures. Sleek and sophisticated, the 3000 Series features black interiors with bright white LED theater lighting, full-text read out U-Select Controls, and limitless integration capabilities with an articulating door hinge. Door finishes are available in stainless steel or integrated panel-ready, and fully adjustable toe-kicks can accept a custom panel to match your surrounding cabinetry.

Features

Cooling System:

• Convection cooling system: Provides a quick cool down and consistent temperature.
• Temperature range: 38°F to 65°F.
• Independently controlled dual-zones.

Interior and Lighting:

• Black interior: Illuminated with LED theater lighting, can be set to stay on for 3, 6, or 24 hours.
• Full-extension black coated wine racks.

Door and Glass:

• LowE coated, argon gas filled, double thermopane glass door: Provides protection from harmful UV light.
• Stainless steel handles: 7⁄8" diameter.
• Integrated model: Requires 3⁄4" custom door panel and handle (not supplied by U-Line).

Wine Racks:

• Accommodates a variety of bottle shapes and sizes.
• Fourth and fifth racks: Allow for larger diameter wine and champagne bottles.

Controls and Display:

• U-Select Control: With digital OLED display.

Capacity:

• Volume: 7.0 cu ft holds up to 62 wine bottles (750 ml).

Design and Build:

• Four adjustable leveling legs.
• Designed to be built-in: Galvanized exterior cabinet.
• Articulating door hinges.
• Adjustable grille: Can be shifted front-to-back and up-and-down, can accept an integrated toe-kick.

Specifications

U-3036WCWCS-00B

• Voltage / Hz: 115 V / 60 Hz
• Finish: Stainless Frame
• Lock: No
• Width: Not specified
• Height: Not specified
• Depth: Not specified
• Weight: 249 lb (113 kg)

Downloads

• CAD-2D (DWG)
• CAD-3D (DWG)
• Compliance
• Current Product Warranty
• Energuide (Canada)
• Expanded View of Parts
• Quick Start Guide
• Spec Sheet
• User Guide & Service Manual

What Our Experts Think

• Dual-Zone Cooling – Independently controlled zones for optimal red and white wine storage.
• Spacious 7.0 Cu. Ft. Capacity – Holds up to 62 wine bottles.
• Smooth-Glide Wine Racks – Minimize vibration while providing easy access.
• UV-Protected Glass Doors – Shields wine from harmful light exposure.
• Digital Touch Controls – Precise temperature management for ideal preservation.
• Energy-Efficient Cooling – Maintains stable temperatures while reducing power consumption.

Q&A

Q: What is the storage capacity of this wine refrigerator?
A: It holds up to 62 wine bottles, with space optimized for various bottle sizes.

Q: Does it have dual temperature zones?
A: Yes, it features independently controlled dual zones to store red and white wines at their ideal temperatures.

Q: What is the temperature range?
A: The upper zone ranges from 38°F to 65°F, while the lower zone ranges from 38°F to 65°F, allowing precise temperature control.

Q: Is the glass door UV-protected?
A: Yes, it includes a UV-resistant, Low-E coated glass door to protect wine from light exposure.

Q: What type of shelving does it have?
A: It features full-extension, smooth-glide wine racks that accommodate various bottle sizes.

Q: Does it have interior lighting?
A: Yes, it has soft LED theater lighting with brightness control to elegantly showcase your collection.

Q: Can this unit be built into cabinetry?
A: Yes, it supports both built-in and freestanding installations for flexible placement.

Q: Is there a security lock?
A: Yes, it comes with a door lock for added protection.

Maintenance Tips

• Wipe the Exterior – Use a soft cloth with mild soap; for stainless steel, apply a stainless steel cleaner to prevent fingerprints and corrosion.
• Clean the Interior & Racks – Remove dust and spills with a damp cloth and mild detergent to keep the wine storage hygienic.
• Check & Maintain Door Seals – Inspect the gasket for dirt or wear, and wipe it down to ensure a tight seal for consistent cooling.
• Monitor & Adjust Temperature – Set optimal temperatures for red and white wines in their respective zones to maintain quality.
• Vacuum the Condenser Coils – Every 6 months, remove dust from the coils to ensure energy-efficient performance.
• Ensure Proper Ventilation – Keep air vents clear to allow consistent airflow and prevent overheating.
• Avoid Overloading – Store bottles properly to allow even cooling and prevent excessive strain on the unit.
