The compact and versatile Marshall Electronics CV503 Mini HD Camera captures at progressive frame rates up to 60p, as well as interlaced, making it suitable for use in live broadcast productions, courtrooms, corporate videos, government assemblies, sportscasts, newscasts, reality television, concerts, and houses of worship. It features a 2.5MP CMOS sensor, with 1920 x 1080 resolution and outputs 3G/HD-SDI. It features an M12 lens mount and comes with a 3.6mm lens. Image tools include Digital Noise Reduction, Auto White Balance, and digital zoom.
Features specific to surveillance include motion detection and privacy mask, allowing you to have the camera trigger if it detects motion in a specific area, as well as being able to mask off an area of the image from surveillance. Audio is handled by the breakout cable that lets you connect a mic- or line-level input device. The breakout cable also features an integrated joystick control for accessing and setting menu items via the on-screen menu display. In addition, you can also control the camera via RS-485 control protocol.
Lens

A removable M12 mounted 3.6mm lens with a 72° angle of view is included with the camera. You can swap out the lens for almost any other Marshall M12 mount lens

• 1/2.8" 2.5MP CMOS Sensor

• M12 Mount with Removable 3.6mm Lens

• Progressive & Interlaced Frame Rates

• 3G/HD-SDI Video Output

Features

Image Control

• Lens Shading: Corrects inconsistent brightness level in the image

• Contrast: Adjusts the image contrast level

• Brightness: Adjusts the image brightness level

• Saturation: Adjusts the image saturation level

• Hue: Adjusts the image hue level

• Edge Enhance: Adjusts the image sharpness level

• Auto Saturate: Decreases saturation automatically when noise scene is detected

• Auto Edge: Adjusts line sharpness level automatically

• Black / White Level: Adjusts the image black level value

• Gamma Correct: Adjusts the image output gamma level

• DNR: Reduces video noise at low ambient light. Select the DNR level from Off, Low, Middle, and High using the Left or Right button

AE Control

• Auto: Adjusts the exposure level automatically. Detailed fine tuning options are available under this menu

• Shut Fix: Provides more detailed shutter speed options. All other controls are tuned for the selected shutter speed

• AGC Fix: Provides more detailed gain option. All other controls are tuned for the selected gain value.

• Manual: Adjusts the exposure level manually

• Shutter: Speed can be set at auto or manual (1/30~1/10,000)

• Iris Speed: Electronic iris speed can be controlled, for DC iris lens only (0~5)

• AGC: Electronic iris speed can be controlled, for DC iris lens only (0~5)

• AGC Max: Used to set maximum gain value to control the video noise caused by Auto Gain Control (Off, Low, Middle, High, DMIN, DMID, DMAX)

• Sens Up: Controls the digital slow shutter to allow extra light into the camera and adjust the picture quality (Off, x2~x10)

• AE Bright: Select this to adjust auto exposure brightness levels (0~10)

• Lens Mode: Lens setting will be optimized for selected environment, for DC iris lens only

• FLK Control: Provides a proper image sensor frequency to match the power frequency in order to minimize video flicker

Digital Tools

• DZoom: Digitally zoom the video by the desired ratio

• Defog: This feature will help increase visibility in extreme weather conditions, such as fog, rain, or in a very strong luminous intensity

• DIS: This feature enables digital image stabilization

• Backlight: Adjusts backlight compensation by choosing either BLC HLM from this menu

• Binning: Enable or disable pixel binning

• Defect Pixel: Advanced defective pixel correction menu

• Disp Function: Display effects such as freeze mirror, rotation, and style can be applied from this menu

• WDR: This feature enables user to view both object and background more clearly when background is too bright

• Flicker Detect: Adjust the image sensor frequency to match the power frequency

• Privacy: Mask an area you want to hide on the screen by applying the privacy zones

What Our Experts Think

• Full-HD Resolution: Captures sharp, high-quality 1080p video, ensuring crisp and clear imagery for broadcast and production applications.
• Compact and Discreet Design: Miniature form factor allows for flexible placement in tight spaces without compromising on performance.
• 3G/HDSDI Compatibility: Supports 3G and HDSDI signals for high-quality video transmission, ensuring professional-grade output in various setups.
• Durable Construction: Built to withstand demanding environments, making it reliable for long-term use in outdoor, sports, and broadcast applications.
• Versatile Mounting Options: Ideal for mounting in confined areas, ideal for use in cameras rigs, surveillance, and live event setups.
• Flexible Integration: Seamlessly integrates with a wide range of video production systems, making it a versatile choice for various workflows.
• Low-Light Performance: Provides excellent performance even in low-light conditions, offering reliable results in a variety of environments.

Q&A

Q: What is the Marshall CV503 camera?
A: The Marshall CV503 is a compact, high-performance miniature Full-HD camera that offers 3G/HD-SDI output. It is designed for professional video production, surveillance, and broadcasting where space is limited but high-quality video is essential.

Q: What makes the CV503 suitable for professional applications?
A: The CV503 delivers Full-HD video with 3G/HD-SDI output, ensuring crisp, clear footage for a variety of professional applications. Its compact size allows for discreet placement, making it ideal for tight spaces or areas requiring minimal visibility.

Q: How does the CV503 perform in terms of video quality?
A: The CV503 provides Full-HD 1080p resolution, ensuring high-quality video output that meets professional standards. With 3G/HD-SDI support, it allows for reliable signal transmission over long distances without loss of video quality.

Q: Is the CV503 suitable for outdoor use?
A: The CV503 is designed for use in controlled environments and is compact enough for various applications, but it doesn't include built-in weatherproofing. For outdoor use, additional housing or protection may be required.

Maintenance Tips

• Inspect for Physical Damage – Regularly check the camera for signs of wear, especially the lens and connectors. Ensure there is no physical damage that could affect image quality or signal integrity.
• Clean the Lens – Use a microfiber cloth to gently clean the lens and remove dust, smudges, or other obstructions to ensure the best image quality.
• Check SDI Connections – Ensure all SDI cables are securely connected and free from corrosion or wear. Loose or damaged cables can cause signal issues.
• Test Signal Output – Periodically test the video output to ensure the camera is delivering Full-HD quality video without any interruptions or signal degradation.
• Avoid Overheating – Keep the camera in a well-ventilated area to avoid overheating, which could reduce performance or shorten its lifespan.
• Firmware Updates – Regularly check for firmware updates to ensure the camera is running the latest software for optimal functionality and compatibility.
• Store Properly – When not in use, store the camera in a cool, dry place to protect it from moisture and temperature extremes.
